MasterLine 8 Elite aluminum window
System cross-section
Product photo
Product photo
Photos are illustrative and not necessarily this exact system.
Aluminum · No. 06 · Architectural
One system, many styles.
U-factor from 0.28 · 3 styles · Architectural custom
MasterLine 8 Elite is built on Reynaers MasterLine 8, a modular aluminum system that architects use when the house has a strong design idea and the windows have to follow it. Three exterior styles, three insulation levels, concealed hinges, glass corners and matching sliding and pivot doors all come from one platform, so a complex custom house can have one consistent window family.
Functional, Renaissance or Deco
- Functional: clean, square, contemporary.
- Renaissance: a sculpted, steel-like profile for traditional or heritage-inspired facades.
- Deco: softer, decorative lines.
Changing style doesn't change the thermal and weather performance.
Built for exposure
Product data lists air tightness class 4, water tightness to 900 Pa (class E900) and wind load class C5, the top European classes. On a west-facing view lot that takes the full winter storm off the water, those numbers matter. Sash weights up to 300 kg and heights to about 9 feet allow big operable sashes.
MasterLine 8 is the system for houses where the architect has already drawn every line.
Options that make the detail
Concealed hinges, concealed drainage (no plastic caps), integrated flyscreens, glass balustrades, motorized sashes and frameless glass corners. The HI+ version adds insulating foams for the best thermal value in the family.
MasterLine 8 Elite specifications
Why choose it: most design options · top weather classes · matching sliding and pivot doors.
Trade-offs: premium price · NFRC rating: ask us for current status for your project · more options mean more decisions; plan time for design.
MasterLine 10 Elite · SlimLine Elite · MB-86N
Who is MasterLine 8 for?
Can I mix styles?
Is there a matching entry door?
Working with an architect?
We're happy to meet with your design team and review details and sizes early.
Specifications
Performance
- U-factor
- from 0.28 Btu/h·ft²·°F
- SHGC
- 0.17–0.42
- Sound
- up to 45 dB (European Rw; system data Rw 46 (0;−3) dB in a tested configuration)
- NFRC rating
- Ask us for current status for your project
- European test classes
- Air 4 · Water E900 · Wind C5
Construction
- System
- Reynaers MasterLine 8
- Frame depth
- 3″ (77 mm)
- Glass thickness
- up to 68 mm
- Insulation levels
- 3, incl. HI+
- Size range
- H 1′11.6″–9′2″, W 1′5.7″–5′6.9″, sash up to 300 kg
Options
- Styles
- Functional, Renaissance, Deco
- Options
- Concealed hinges, concealed drainage, flyscreen, balustrade, motorized, glass corner
- Doors
- Matching sliding and pivot doors
- Nailing fin
- Available
Ordering
- Lead time
- 3–4 months; made to order and shipped by sea freight
- Warranty
- 20-year limited manufacturer warranty; 3-year installation warranty. See warranty terms
